8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box

Certification
China Shenzhen damu technology co. LTD certification
China Shenzhen damu technology co. LTD certification
I'm Online Chat Now

8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box

8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box
8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box
8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box

Large Image :  8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box

Product Details:
Place of Origin: China
Brand Name: DAMU
Certification: CE ROSH ISO9001
Model Number: DM-PS-8
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Packaging Details: 1000M/Wood Roll,Size of Wood Roll:103*103*66cm, Weight:240KG . We accept OEM length(2km-5KM all ok)
Delivery Time: 5-8
Payment Terms: T/T
Supply Ability: 50000pcs/month

8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box

Description
Product Name: Plc Splitter Fiber Type: G657A1
Application: FTTH FTTB FTTX Network Operating Temperature: -40℃ To 85℃
Connector: SC/APC/UPC Warranty: 3 Years
Color: 12 Colors Are Available Fiber Length: 1m Or Customized
Capacity: 1x8 Return Loss: ≥50 DB,APC≥60dB
Cable Diameter: 0.9mm Connector Type: SC

8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box



Parameter of PLC Splitter

1XN



Parameter



Unit



Specification

    1x2 1x4 1x8 1x16 1x32 1x64
Operate wavelength nm 1260-1650
Insertion loss standard dB 3.6 7.0 10.2 13.3 16.5 20.0
  MAX(p/s)   3.8/4.0 7.2/7.4 10.5/10.7 13.5/13.9 16.5/17.2 20.0/21.5
PDL dB ≤0.2 ≤0.2 ≤0.2 ≤0.3 ≤0.3 ≤0.3
Lossuniformaity dB ≤0.6 ≤0.8 ≤1.0 ≤1.4 ≤1.6 ≤1.9
Return loss@1550nm dB ≥55 ≥55 ≥55 ≥55 ≥55 ≥55

Wavelengthdependent

loss

dB ≤0.5 ≤0.5 ≤0.5 ≤0.5 ≤0.5 ≤0.5
Fiber length m 1.2(±0.1) or customer specified
Fiber length   Corning SMF-28eor customer specified
Fiber type dB ≤0.5

Temperature stability(-40

to +85)

dB ≤0.5

Operating/storage

temperature

-40 to +85
Max optical power mw 300



FTTH 1x4 1x8 1x16 1x32 Micro Fiber Optical PLC Splitter

Fiber Optical PLC Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. Raiwav provides whole series of 1xN and 2xN splitter products that are tailored for specific applications.





Characteristic of PLC Splitter

1. Fiber To The Home (FTTH)

2. Local Loop Passive Optical Networks (PON)

3. Fiber Optic CATV Fiber Communication Systems

4. Fiber Optic Test Equipment

5. Fiber Optic Sensing

6. Local Area Networks (LAN)



Feature

1. Low return loss

2. Low PDL

3. High directivity

4. Good uniformity

8 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 08 Way Optical Fiber Opticl Splitter 1*8 Sc Apc Plc Splitter G657A1 Calbe For Terminal Box 1

FAQ

1.who are we?
We are based in Guangdong, China, start from 2018,sell to Eastern Europe(18.00%),Western Europe(13.00%),Northern
Europe(11.00%),South Asia(10.00%),North America(9.00%),Mid East(8.00%),Central America(7.00%),South America(7.00%),Eastern
Asia(6.60%),Africa(5.00%),Domestic Market(2.20%),Southern Europe(1.20%),Oceania(1.00%),Southeast Asia(1.00%). There are total
about 11-50 people in our office.

2.how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
fiber optic polishing machine,fast connector,fiber optic polishing jig,fiber optic patch cord

4.why should you buy from us not from other suppliers?
12 years of experience advanced level in optical fiber equipment, we have OEM and ODM capabilities. We have always been in the
leading position in the same industry with superb workmanship, excellent quality, good pre-sales and after-sales services.

5.what services can we provide?
Accepted Delivery Terms: FOB,EXW;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese
